Description
Technical Parameters

Corrugated steel siding panels are suitable for various indoor and outdoor advertising displays, signboards, directional signs, advertising boards, display walls, and other applications. The Board's advantages are good durability, ease to clean, simple installation, and beautiful appearance, making it a high-quality advertising display material. The special structure and material of the board can also achieve good sound insulation, heat preservation, and seismic performance, suitable for applications that require high-performance materials.


Advantages of Products
Easy installation :
The metal sandwich board is Lightweight and small in size, the weight per square meter is 3.7 kilograms. Not restricted by seasonal climate and geographical environment, saving costs.
Good performance:
The metal sandwich board is waterproof, moisture-proof, earthquake-proof, crack-proof, heat insulation, fire and sound insulation.
High insulation value, low energy consumption;
Easy to install, reduce cost ;
Lightweight & High hardness, earthquake proof;
Thermal and Sound insulation & inflaming retarding
The better decorative effect, more design choices
Production of PU sandwich panel

Packing & Shipping

FAQ
Hot Tags: corrugated steel siding panels, China corrugated steel siding panels manufacturers, suppliers, factory, Fire Resistant Foam Board, Metal Sandwich Panel Wall, Polyurethane Composite Board, PU Foam Insulation Panels, Wood Grain Metal Siding, Wood Grain Metal Siding for House
|
Product name |
Corrugated Steel Siding Panels |
|
Thickness |
9mm, 14mm, 16mm, 20mm, 25mm, 30mm |
|
Width |
38.3cm |
|
Length |
Based on user requirements |
|
Surface layer |
Galvanized steel sheet |
|
Steel coating |
HDP, >30µm |
|
Core materials |
Polyurethane, 42kg/m³ |
|
Closed cell rate |
>95% |
|
Bottom material |
Aluminum foil |
|
Thickness of bottom material |
0.26mm |
|
R-VALUE |
0.55㎡*k/w |
|
Heat conductivity |
0.024w/m*k(in theory) |
|
Certificate |
ISO9001,CE |
|
Fire resistance level |
B1/B2 |
|
Size tolerance |
=/-2mm |
|
Tensile bond strength |
0.17MPA |
|
Wind load value |
9KPA |
|
Package |
corrugated box, 10 pieces/carton |
