Your Professional Roof Tile Supplier
Shandong Xinzhong New Materials Company has been based in Jinsha Industrial Park, Shahe Town, Shanghe County—the northern gateway to Jinan—since 2014, beginning its journey toward success. As a professional manufacturer that integrates design, R&D, production, and sales, we have been deeply engaged in the fields of composite materials and metal insulation materials. From lighting tiles to fiberglass tiles, and from fiberglass products to sandwich wall panels, each product reflects our dedication and expertise. Our products are not only aesthetically pleasing but also offer many advantages, such as excellent thermal insulation, fire resistance, environmental protection, corrosion resistance, anti-aging properties, light weight, and high strength.
Why Choose Us
Production Advantages
Our products are not only beautiful but also feature outstanding properties, such as excellent thermal insulation, fire resistance, environmental protection, corrosion resistance, anti-aging, light weight, and high strength.
Production Equipment
Our state-of-the-art production lines ensure product quality. Advanced machines such as embossing machines, keel machines, and cutting machines work in harmony, like precision instruments playing the tune of efficient production. We have mastered the core technologies and have achieved full coverage of the entire industry chain. From the careful selection of raw materials to the flawless presentation of finished products, every step is meticulously controlled.
Production Market
Thanks to their excellent quality, our products are widely sold both domestically and internationally. They are found in countries like the United States, South Korea, Japan, Malaysia, Singapore, and more. They are also popular in regions such as Macau, Taiwan, and other parts of China, where they are well received in the construction and decoration industries.
Technical Parameters
|
Environment |
Polluting or environmentally friendly |
No asbestos and Environment friendly. Recycling material |
|
Heat distortion temperature |
Below 70.0℃ |
No change |
|
Softening temperature |
Below 75.2℃ |
No softening |
|
Difficult to burn |
B1 |
Oxygen index 35 |
|
Surface thickness |
≥0.15mm |
≥0.18mm |
|
Flexural modulus of elasticity |
MPa 2200 |
≥3820 |
|
Corrosion resistance |
Acid resistance(H2 SO4,20%v/v,24h) |
No change |
|
Freeze thaw resistance |
1kg steel ball filling down on the tile from 2 meters height. The roof tile without any crack. |
No crack bubble etc. |
|
Anti-aging test |
Light source wave length: 290-800mm |
1.Life time 6000hours(same as common environment 50 years) |
|
Fade |
ASTM D2244 |
▲E*≤5, ▲b≤3 |
|
UV light |
PMMA material |
Anti 27% UV light |
|
No. |
Test Item |
Unit symbol |
Standard |
Test Result |
Judgment Result |
|
1 |
Width deviation |
MM |
±10.0 |
-1 |
Qualified |
|
2 |
Thickness |
MM |
≥2.8 |
2.98 |
Qualified |
|
3 |
Surface layer thickness |
MM |
≥0.15 |
0.161 |
Qualified |
|
4 |
Size change rate after heating |
% |
±2.0 |
0.6 |
Qualified |
|
5 |
Heating state (150 ℃, 30 minutes) |
/ |
No bubbles, cracks, or spots should be produced |
Qualified |
Qualified |
|
6 |
Low temperature drop hammer impact (-10 ℃, 1kg, 1.0m) |
(个） |
Number of ruptures≤1 |
0 |
Qualified |
|
7 |
Oxygen index |
% |
≥32 |
≥33 |
Qualified |
|
8 |
Bearing performance (span 660mm, deflection 3%) |
N |
≥800 |
1525 |
Qualified |
|
9 |
Stress cracking resistance |
/ |
No cracks, no separation |
Qualified |
Qualified |
|
10 |
Density |
G/cm³ |
≤1.85 |
1.67 |
Qualified |
|
11 |
Bending strength |
MPa |
≥40 |
48 |
Qualified |
|
12 |
Bending modulus of elasticity |
MPa |
≥2200 |
3150 |
Qualified |
|
13 |
Tensile fracture strength |
MPa |
≥20 |
27 |
Qualified |
|
14 |
Nominal fracture strain |
% |
≥15 |
65 |
Qualified |
|
15 |
Notched impact strength of simply supported beams |
KJ/㎡ |
≥40 |
110 |
Qualified |
|
16 |
Vicat softening temperature (B50) |
℃ |
≥75 |
84 |
Qualified |
Product Feture
1. Excellent Corrosion Resistance:
The synthetic resin roof tiles and their surface offer excellent corrosion resistance. They will not be eroded by rain or snow and can resist long-term exposure to acids, alkalis, salts, and other chemicals. Experimental results show that the product will not deform or fade when submerged in a solution of 40% NaOH and 40% H₂SO₄ for 24 hours. Microbes of all kinds cannot survive on the tile's surface.
2. Lightweight, High Strength, Easy to Install:
ASA PVC roof tiles are lightweight structural materials, weighing (6.0±0.2) kg/m², effectively reducing the load on the building and improving safety. They are especially suitable for the renovation of old buildings. At the same time, their light weight makes them easy to handle and install, reducing freight costs and construction expenses. With complete accessories and customizable lengths, installation is easy, improving paving efficiency and saving costs.
3. Strong Fire Resistance:
The main material, PVC resin, is inherently flammable; however, the fire performance has been tested and meets B1 level according to national fire department standards.
4. Self-Cleaning Property:
The surface of the ASA PVC roof tile is smooth and compact, making it resistant to dust accumulation. Once washed by rain, the tiles look as good as new, and there is no risk of scaling.
5. Sound Insulation, Heat Insulation:
High-quality anti-corrosion synthetic resin roof tiles have passed phoneme determination tests, showing their ability to absorb and reduce noise. They perform well in mitigating external noise, such as from rainstorms, hail, and gales. With a thermal conductivity of 0.325 W/m·K, the tiles are 1/30 as conductive as clay tiles, 1/5 as conductive as thick cement tiles, and 1/2000 as conductive as 0.5mm thick color steel tiles. Even without adding an insulation layer, they provide excellent thermal insulation performance.
Sheds,Villas,Holiday villages,Mobile Homes,Prefabricated House,Garden Pavillion,Farm Stay,many other types of residential and commercial buildings.
Colors show
As follow is existing color in factory ,and welcome custom color as demand.
FAQ
As one of the leading roof tile manufacturers and suppliers in China, we warmly welcome you to buy high-grade roof tile for sale here from our factory. All our products are with high quality and competitive price.
